Fish cooker
Short Description:
Discription:
The Fish Cooker consists of a stator housing with steam-heated jacket and a screw rotor with flights that are mounted on the whole length of the rotor. Rotor and flights are indirectly heated by steam. The stator steam jacket is divided into sections, enabling uniform distribution of the steam by means of a steam manifold. The condensate from the jacket is discharged through a condensate manifold. The housing is equipped with hinged hatches with counterweights for efficient inspection and cleaning. The rotor is equipped with stuffing boxes in both ends. The rotor is supported at both ends only by means of roller bearings. Steam enters and condensate is evacuated through the rotary joint mounted on the end shaft.
|
Cooker type |
Capacity (t/h) |
Dimensions |
Weight (Metric ton) |
||
|
|
|
L |
W |
H |
|
|
XFC0603 |
1.6-2.0 |
5500 |
740 |
1640 |
1.4 |
|
XFC0605 |
2.6-3.25 |
7500 |
740 |
1640 |
3.4 |
|
XFC0806 |
6.4-8.0 |
8500 |
940 |
1841 |
7.4 |
|
XFC0808 |
8.8-11.0 |
10500 |
940 |
1841 |
8.5 |
|
XFC1108 |
12.8-16.0 |
10560 |
1240 |
2196 |
12.3 |
|
XFC1110 |
16.0-20.0 |
12560 |
1240 |
2196 |
14.7 |
|
XFC1112 |
20.0-25.0 |
14560 |
1240 |
2196 |
17.2 |
|
XFC1310 |
20.0-25.0 |
12352 |
1376 |
2386 |
20 |
|
XFC1312 |
24.0-30.0 |
14352 |
1376 |
2386 |
24 |
|
XFC1314 |
28.0-35.0 |
16352 |
1376 |
2386 |
30 |
|
XFC1612 |
30.4-38.0 |
15570 |
1740 |
2820 |
27 |
|
XFC1614 |
35.2-44.0 |
17570 |
1740 |
2820 |
33 |
|
XFC1616 |
40.0-50.0 |
19570 |
1740 |
2820 |
38 |
Continuous Cooker
Details
：
FOB Price:US $7900-47600 / Piece
Min.Order Quantity:1 Piece/Pieces
Supply Ability:10sets per month
Port:Qingdao
Payment Terms:
L/C,D/A,D/P,T/T
Short Description:
Discription:
The Fish Cooker consists of a stator housing with steam-heated jacket and a screw rotor with flights that are mounted on the whole length of the rotor. Rotor and flights are indirectly heated by steam. The stator steam jacket is divided into sections, enabling uniform distribution of the steam by means of a steam manifold. The condensate from the jacket is discharged through a condensate manifold. The housing is equipped with hinged hatches with counterweights for efficient inspection and cleaning. The rotor is equipped with stuffing boxes in both ends. The rotor is supported at both ends only by means of roller bearings. Steam enters and condensate is evacuated through the rotary joint mounted on the end shaft.
|
Cooker type |
Capacity (t/h) |
Dimensions |
Weight (Metric ton) |
||
|
|
|
L |
W |
H |
|
|
XFC0603 |
1.6-2.0 |
5500 |
740 |
1640 |
1.4 |
|
XFC0605 |
2.6-3.25 |
7500 |
740 |
1640 |
3.4 |
|
XFC0806 |
6.4-8.0 |
8500 |
940 |
1841 |
7.4 |
|
XFC0808 |
8.8-11.0 |
10500 |
940 |
1841 |
8.5 |
|
XFC1108 |
12.8-16.0 |
10560 |
1240 |
2196 |
12.3 |
|
XFC1110 |
16.0-20.0 |
12560 |
1240 |
2196 |
14.7 |
|
XFC1112 |
20.0-25.0 |
14560 |
1240 |
2196 |
17.2 |
|
XFC1310 |
20.0-25.0 |
12352 |
1376 |
2386 |
20 |
|
XFC1312 |
24.0-30.0 |
14352 |
1376 |
2386 |
24 |
|
XFC1314 |
28.0-35.0 |
16352 |
1376 |
2386 |
30 |
|
XFC1612 |
30.4-38.0 |
15570 |
1740 |
2820 |
27 |
|
XFC1614 |
35.2-44.0 |
17570 |
1740 |
2820 |
33 |
|
XFC1616 |
40.0-50.0 |
19570 |
1740 |
2820 |
38 |
